indoor AVOE LED display board P4 indoor led wall For advertising 1200nits
Features:
1. High definition and could be adjusted, so it can meet the request of the customers according the application environments
2. Wide application, good for rental or fixed installation
3. Adopt high-intensity aluminum, has a better anti-rust and corrosion resistant capacity
4. with 10KG in weight and 70mm in thickness. Common cabinet with 20KG in weight and thickness with 100mm
5. 48 hours for led module test and 72 hours for led screen test to ensure the perfect quality.
Work temperature -20~+40 deg
6. Professional lock design makes seamless connection available
7. High gray scale and stable performance,realize the HD and exquisite image
Widely applications:
Mainly used to do outdoor advertisement just like TV, in addition, it also can be used to play the Events, Showing, Cinema, Sports, etc.
Parameters
| Model No. | P4-A | P4-B | P4-C |
| Pixel Pitch (mm) | 4 | 4 | 4 |
| LED Configuration | SMD2121 | SMD2121 | SMD2121 |
| Module Size (mm) | 320*160 | 256*256 | 256*128 |
| Resolution(dot) | 80*40 | 64*64dot | 64*32 |
| Pixel Density(dot/㎡) | 62500 | 62500 | 62500 |
| IP Rating | IP30 | IP30 | IP30 |
| Scanning Mode | 20S | 32S | 16S |
| Brightness CD/㎡ | 1000 | 1000 | 1000 |
| Viewing Angle | 160°/ 140°(H/V) | 160°/ 140°(H/V) | 160°/140°(H/V) |
| View Distance | >3m | >3m | >3m |
| Gray | 14bit | 14bit | 14bit |
| Color | 16.7M | 16.7M | 16.7M |
| Max/Ave Consumption(W/㎡) | 550/200 | 460/160 | 480/170 |
| Refresh Rate(Hz) | ≥1920 | ≥1920 | ≥1920 |
| Gamma Coefficient | -5.0~ + 5.0 | -5.0~+5.0 | -5.0~+5.0 |
| Application Environment | Indoor | Indoor | Indoor |
| Brightness Adjustment | 0-100 levels adjustable |
| Control System | Synchronous display with control PC by DVI |
| Video Format | Composite, S-Video,Component, VGA. DVI, HDMI, HD_SDI |
| Power | AC100~240 50/60HZ |
| Working Temperature | -20°C~+50°C |
| Working Humidity | 10~95% RH |
| Life Span | 50,000hours |
